DarkStar22 CineWhoop (WTFPV)
DarkStar22 CineWhoop (WTFPV)
Järeletulemise saadavust ei õnnestunud laadida
The DarkStar22 combines high performance with portability, equipped with the DJI O4 Pro VTX system, delivering ultra-low latency, HD stable long-range transmission.
It features the latest TAKER F405 20A ELRS2.4 2-4S AIO flight controller with an integrated receiver, eliminating the need for an additional RX and ensuring compatibility with all mainstream ELRS protocol radios. The innovative five-point floating damping system provides a stable working environment for the O4 Pro gyro, enabling smooth and stabilized video output.
With a reserved GPS mount, pilots can enjoy safer flights in complex outdoor environments. The SPEEDX2 1104 7500KV motors, paired with newly designed high-efficiency 2219 props, deliver a strong punch while maintaining an excellent balance of power and endurance.
The entire build is compact, reinforced with a thickened canopy and prop guards for crash resistance, making it beginner-friendly and safe to fly both indoors and outdoors. Truly a performance beast among micro cinewhoops!
Specifications (WTFPV)
- Model: DarkStar22 WTFPV
- Frame: GEP-DS22
- Main Carbon Plate Thickness: 2.5mm
- Wheelbase: 100mm
- FC System: TAKER F405 20A ELRS2.4 2-4S AIO
- MCU: STM32F405
- Gyro: ICM42688-P
- FC Firmware: GEPRC_TAKER_F405 AIO
- Flash: 16MB
- ESC: 8Bit 20A
- Motor: SPEEDX2 1104 7500KV
- Propellers: GEPRC x GEMFAN GP2219-3
- Power Connector: XT30U-M
- VTX: None
- Camera: None
- Antenna: None
- Receiver: PNP (O4 Pro built-in RX) / ELRS 2.4G
- Weight (ELRS 2.4G version): 98.0g
- Recommended Battery: GEPRC Storm LiHV 3S 720mAh
Included
- 1x DarkStar22 Drone
- 1x Prop Guard
- 1x Top Plate
- 1x Camera Cover
- 1x Battery Pad
- 2x Propellers (pairs)
- 1x 10*120mm Battery Strap
- 1x L-shaped Hex Wrench 1.5mm
- 1x Battery Anti-slip Pad
- 1x Damping Ball Punch Tool
- 1x Binding Pin
- 1x USB Adapter Board
- 1x 5P Terminal Cable
- 1x Hardware set
